UNIVERSAL JOINT POLARIS, ALLBALLS 19-1016

All Balls U-Joint Kit – 19-1016

Features:

• Material: Cold forged from SCM-415 steel for durability.
• Precision: Precision ground journals are case hardened to HRC58-61.
• Greasing: Pre-greased with high-temperature Lithium Complex 3 grease.
• Design: Zerk and grease channels in bearing cup for even grease distribution.
• Additional: Includes a cap plug to eliminate the grease zerk for low clearance applications.

Applications:

Front Drive Shaft – Differential Side (Ref 2):

Polaris:

Scrambler:

• 1000 MD (2015-2017)
• 1000 MD Built After 2/16/16 (2016)
• 1000 MD Built Before 2/15/16 (2016)
• 1000 Tractor (2016-2017)
• 1000 XP (2015-2017)
• 1000 XP EU (2015)
• 1000 XP HO EPS (2014-2015)
• 1000 XP HO EPS INTL (2014)
• 850 (2015-2017)
• 850 EU (2015)
• 850 HO/EPS (2013-2014)
• 850 MD (2015)
• 850 XP HO EPS (2014)
• 850 XP HO EPS INTL (2014)

Sportsman:

• 1000 MD (2015)
• 1000 MD Built After 2/16/16 (2016)
• 1000 MD Built Before 2/15/16 (2016)
• 1000 XP (2015-2017)
• 1000 XP Tractor (2017)
• 1000 XP Tractor Built After 2/16/16 (2016)
• 1000 XP Tractor Built Before 2/15/16 (2016)
• 550 (2012-2013)
• 550 EPS (2012-2014)
• 550 X2 (2012-2014)
• 550 X2 EPS LE (2014)
• 550 X2 INTL (2014)
• 550 XP (2013-2014)
• 550 XP EPS HD INTL (2014)
• 850 SP (2015-2017)
• 850 WV (2014)
• 850 XP HO EPS MD (2015)
• Forest 1000 EU (2015)
• Forest 550 (2012-2014)
• Forest 850 (2012-2015)
• Forest 850 EU (2015)
• Touring 1000 (2015-2017)
• Touring 550 EPS (2012-2014)
• Touring 850 EPS (2014)
• Touring 850 INTL (2014)
• Touring 850 SP (2015-2017)
• Touring EPS 850 (2012-2013)
• Touring EPS 850 HO (2013)
• XP 850 (2012-2013)
• XP 850 EPS (2012-2014)

Front Drive Shaft – Differential Side, Outside Clip (2-Alt):

Polaris:

Sportsman:

• XP 850 EPS (2011)
• 550 (2011)
• 550 EPS (2011)
• 550 X2 (2011)
• Forest 550 (2011)
• Forest 850 (2011)
• Touring 550 EPS (2010-2011)
• Touring EPS 850 (2011)
• X2 850 (2011)
• XP 850 (2011)

Front Drive Shaft – Engine Side (Ref 3):

• Polaris: Same models and years as listed for Differential Side (Ref 2)

Part Number: 17-3320.A (oro2u.com)

Additional All Balls U-Joint Kits Applications:

• Location 1: Front Axle Inner
• Location 2: Front Drive Shaft (Differential Side)

Specific Polaris Models:

• 550 Sportsman EPS (2012-2013)
• 550 Sportsman X2 (2012-2013)
• 550 Sportsman (2012-2013)
• 550 Sportsman Forest (2012-2013)
• 550 Sportsman Touring EPS (2012-2013)
• 850 Scrambler HO/EPS (2013)
• 850 Sportsman Forest (2012-2013)
• 850 Sportsman Touring EPS (2012-2013)
