REGULATOR VOLTAGE 12V / 25A VT600, 31600-MM8-00331600-MM8-02831600-MY0-771, AHA6043, ROAD, MC, HX RF009
Brand: Arrowhead Electrical
Stock: 1
| Product Type | Voltage Reulator |
|---|---|
| Product Group | Ignition & Electrical Parts |
| Catalogue | ROAD |
REGULATOR VOLTAGE 12V / 25A VT600, 31600-MM8-00331600-MM8-02831600-MY0-771, AHA6043, ROAD, MC, HX RF009
Honda
VT600 Shadow VLX 1988-2007,
VT600 Shadow VLX Deluxe 1993-2007,
SHADOW VLX (VT600C) (DELUXE) 1988-2007,
VT Shadow 600
VT C 600cc (1988)
VT C 600cc (1988 – 1991)
VT C 600cc (1988 -1989)
VT C / CD 600cc (1988 – 2007)
VT Nighthawk GT 650cc
VT Revere 650cc
| Technical specifications | |
| Tension (voltage) | 12 [V] |
| Corriente (current) | 25 [A] |
| Tipo de entrada (input type) | TRIFASICO |
| Tecnologia (technology) | SCR |
| Tipo de salida (output type) | CC |
| Alto (height) | 28 [mm] |
| Ancho (width) | 80 [mm] |
| Largo (length) | 90 [mm] |
| Entre centro (pitch) | 67 [mm] |
| Con sensor (with sensor) | NO |
| dze products that apply to | |||||
| Brand | Model | Version | Displacement | Year | OEM |
| Honda | VT | Shadow | 600 | 31600-MY0-771 | |
| Honda | VT | C | 600 | 1988 | 31600-MR1-000 |
| Honda | VT | C | 600 | from 1988 to 1991 | 31600-MR1-003 |
| Honda | VT | C | 600 | from 1988 to 1989 | 31600-MR1-010 |
| Honda | VT | C / CD | 600 | from 1988 to 2007 | 31600-MY0-771 |
| Honda | VT | Nighthawk GT | 650 | 31600-MY0-771 | |
| Honda | VT | Revere | 650 | 31600-MY0-771 | |
– Meets or exceeds OEM quality.
– Direct oem replacement.
– All products are factory tested for 100% reliability at point of sale
– DZE Racing products are a high quality replacement part and carries our guarantee of your satisfaction.
– Note. No Returns on Electrical Parts.
Part No. 44-0987 (oro2u.com)
Cross reference numbers ONLY.
31600-MY0-771, 2061, AHA6043, RICKS 10-124, 2112-0176,
Dimensions: 80mm L x 90mm W x 28mm Hole Distance 66mm
Honda Steed 400 Honda VF 750 C MAGNA 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003
Honda VF 750 CD MAGNA DELUXE 1995 1996 Honda VF 750 C2 MAGNA DELUXE 1997 1998 1999 2000 Honda VT 600 C SHADOW VLX 1992 1993 1994 1995 1996 1997 Honda VT 600 C SHADOW VLX 1999 2000 2001 2002 2003 2004 2005 Honda VT 600 CD SHADOW DELUXE 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 Honda VT 600 CD2 SHADOW 1999 2000 Honda CH250
