PISTON KIT VERTEX 53.0 KAWASAKI KX 100 98-22, VERTEX 23621050 OS +050 RACE SINGLE RING

VERTEX UK PISTON KIT           23621050         RACE 1-RING   (Distributed by oro2u.com)

All Vertex Pistons Feature:
– Standard pistons and components are OEM replacements.
– Kits include piston, rings, wrist pin and circlips.
– All pistons are heat treated with a T-5 or T-6 hardening and tempering cycle.
– Replacement rings are sold individually.
– Made in Italy.
– Fitted in many oem bikes as STD.

SPECIFICATIONS

• BORE SIZE.   53.00mm   OVER SIZE +0.50mm [A   52.94mm]

Replacement Parts.

• Rings.   53010005300
• Pin.   715286
• Clips. 72050

Cross reference numbers ONLY.

• PISTON-ENGINE   13001-0759
• PIN-PISTON   13002-1018
• RING-PISTON TOP 13003-1274
• RING-SNAP   92033-0005

MODEL FITMENT

• KAWASAKI KX 100 1998-2013 RACE SINGLE RING
• KAWASAKI KX 100 2014-2022 SINGLE RING
