PISTON KIT SACHS 125/7 55.75, WOSSNER 8287D200 PIN 16mm

This Wossner forged piston kit with a 55.75mm bore is an oversized (+2.00mm) replacement for the Sachs 125/7 engine. Precision-forged in Germany, it is engineered for strength, thermal efficiency, and longevity. The elliptical piston profile promotes even expansion and load distribution, reducing localised stress and preventing failure under two-stroke operating conditions.

Features

• Forged construction for high durability and performance

• Optimised for efficient heat transfer from combustion to cylinder walls

• Elliptical design provides uniform bearing surface under thermal expansion

• Even thrust load distribution minimises localised pressure points

• Manufactured in Germany

Specifications

• Bore: 55.75mm (+2.00mm Oversize)

• Actual bore: 55.69mm

• Display volume: 122 cm³

• Stroke: 54.00mm

• Clearance: 0.06mm

• Wossner compression ratio: 2-stroke

• OEM compression ratio: 2-stroke

• Compression height: 38.00mm

Cross-Reference OEM Part Numbers

• 56-W9844.200

• 8287D200

• Clip Part Number: CW16

• Pin Part Number: WP136

• Ring Set Part Number: RSB5575 (x2)

Vehicle Fitments

• Sachs 125/7
