| Size | 68.50mm |
|---|---|
| Product Type | Pistons & Kits |
| Product Group | Engine |
| Catalogue | DIRT, ROAD |
| Piston Diameter | 68.50 |
| Bore Diameter | |
| Piston Grade | |
| Compression Ratio |
PISTON KIT 90-91 KX250 68.50, WOSSNER 8109D110 KAWASAKI MX
Wossner Forged Piston Kit 68.50mm Bore – Kawasaki KX250 / KDX250 (1990–1994)
This Wossner forged piston kit is made for Kawasaki KX250 and KDX250 models produced between 1990 and 1994. With a bore size of 68.50 mm and a piston diameter of 68.44 mm (+1.10 mm oversize), it is designed for overbored or re-sleeved cylinders. The piston’s forged construction ensures enhanced durability, while its elliptical shape promotes even pressure distribution under thermal expansion. Precision-manufactured in Germany for high-performance reliability.
Features
-
Forged piston for maximum strength and extended durability
-
Optimised combustion heat transfer to maintain cylinder integrity
-
Elliptical geometry provides consistent load distribution and minimises piston wear
-
Manufactured in Germany for precision and consistency
Specifications
-
Bore Size: 68.50 mm
-
Piston Diameter: 68.44 mm
-
Engine Displacement: 250 cm³
-
Stroke: 70.00 mm
-
Clearance: 0.06 mm
-
Compression Height: 37.00 mm
-
Compression Ratio: 2-stroke (Wossner and OEM)
Cross-Reference Wossner Part Numbers
-
Piston Kit: 8109D110
-
Lock: CW18
-
Pin: WP033
-
Ring Set: RSB6850
-
Rod: P2022
Vehicle Fitments
-
1990 Kawasaki KX250
-
1991 Kawasaki KX250
-
1991 Kawasaki KDX250
-
1992 Kawasaki KDX250
-
1993 Kawasaki KDX250
-
1994 Kawasaki KDX250
