| Size | 67.5mm |
|---|---|
| Product Type | Pistons & Kits |
| Product Group | Engine |
| Catalogue | ATV |
PISTON KIT 88-92 LT250 67.50, WOSSNER 8259D050 SUZUKI ATV
The Wossner 8259D050 piston kit is engineered for Suzuki LT250 ATV models from 1988 to 1992, featuring a 67.50 mm bore for +0.50 mm oversize applications. Manufactured in Germany from forged materials, this piston provides superior durability and optimised heat transfer. Its elliptical shape promotes even bearing surface contact under heat expansion, reducing localised stress and preventing piston collapse. The kit includes all necessary components for a reliable engine rebuild.
Features
-
Forged piston construction for maximum strength and durability
-
Engineered for optimal heat dissipation from combustion chamber to cylinder wall
-
Elliptical profile ensures even distribution of thermal expansion pressure
-
Reduces localised stress to prevent piston collapse
-
Precision-manufactured in Germany
Specifications
-
Bore Size: 67.50 mm
-
Actual Bore Diameter: 67.44 mm
-
Stroke: 70.00 mm
-
Display Displacement: 246 cm³
-
Clearance: 0.06 mm
-
Compression Ratio (Wossner and OEM): 2-stroke
-
Compression Height: 37.20 mm
Cross-Reference Wossner Part Numbers
-
Piston Kit: 8259D050
-
Lock: CW18
-
Pin: WP033
-
Ring Set: RSB6750 (Quantity: 2)
-
Part No.: 56-W571+0.50.WO
Vehicle Fitments
-
Suzuki LT250 (1988–1992)
