| Size | 83.00mm |
|---|---|
| Product Type | Pistons & Kits |
| Product Group | Engine |
| Catalogue | DIRT |
| Piston Diameter | 83.00 |
| Bore Diameter | |
| Piston Grade | |
| Compression Ratio |
PISTON KIT 2013 EC300F 83.00 A, WOSSNER 8875DA
Wossner forged piston kit 8875DA is a standard-size piston with an 83mm bore (measured at 82.94mm) designed for the GASGAS EC300F 4-stroke model from 2013 onward. Engineered for strength, precision, and optimal thermal transfer, this German-made piston kit is ideal for reliable engine performance and durability.
Features
-
Forged piston construction for maximum strength and durability
-
Elliptical design for consistent bearing surface under heat expansion
-
Efficient combustion heat transfer to cylinder walls
-
Prevents piston collapse through even thrust load distribution
-
Made in Germany
Specifications
-
Bore: 83mm (Measured: 82.94mm)
-
Display Volume: 290 cm³
-
Stroke: 53.60mm
-
Clearance: 0.06mm
-
Compression Height: 22.20mm
-
Wossner Compression Ratio: OEM
-
OEM Compression Ratio: 13.50:1
-
Dome Volume: -6.30 cm³
-
Part No.: 56-W912.A.WO (Wossner 8875DA)
-
Ring Set: 830XDS
-
Lock P/N: CW16
-
Pin P/N: WP059
Vehicle Fitments
-
2013–onward GASGAS EC300F (4-stroke)
