| Size | 56.75mm |
|---|---|
| Product Type | Pistons & Kits |
| Product Group | Engine |
| Catalogue | DIRT |
| Piston Diameter | 56.75 |
| Bore Diameter | |
| Piston Grade | |
| Compression Ratio |
PISTON KIT 1984 YZ125 56.75, WOSSNER 8120D075 YAMAHA MX
This Wossner forged piston kit with a 56.75mm bore (56.69mm) is designed for the 1984 Yamaha YZ125. Manufactured in Germany, it delivers improved strength and efficient thermal conductivity. Its elliptical design ensures a more uniform bearing surface under heat expansion, promoting even thrust load distribution and reducing the risk of piston collapse.
Features
-
Forged piston for enhanced strength and durability
-
Designed for optimal heat transfer from combustion to cylinder walls
-
Elliptical profile provides uniform pressure distribution under thermal expansion
-
Made in Germany
Specifications
-
Bore size: 56.75mm (56.69mm)
-
Display volume: 123 cm³
-
Stroke: 50.00 mm
-
Clearance: 0.06 mm
-
Compression height: 30.80 mm
-
Theoretical weight: Not specified
-
Compression ratio: 2-stroke (Wossner and OEM)
Cross-Reference OEM Part Numbers
-
Piston: 8120D075
-
Lock: CW16
-
Pin: WP036
-
Ring Set: RSB5675
Vehicle Fitments
-
Yamaha YZ125 1984
