| Size | 56.00mm |
|---|---|
| Product Type | Pistons & Kits |
| Product Group | Engine |
| Catalogue | DIRT, ROAD |
| Piston Diameter | 56.0 |
PISTON KIT 125 MITO 93-8 56mm, CAGIVA 8053DB WOSSNER
This Wossner forged piston kit is a +0.01mm oversize replacement for Cagiva 125cc two-stroke engines, suitable for Mito, Raptor, Supercity, Planet, W8, and Head 200H,M models from 1993 to 2012. It offers exceptional durability and fitment for engines requiring a minor bore increase.
Features
-
Forged piston design for maximum strength and resistance to wear
-
Elliptical profile ensures uniform bearing surface during thermal expansion
-
Optimised for efficient combustion heat transfer to cylinder walls
-
Reduces localised pressure and risk of piston collapse
-
Manufactured in Germany
Specifications
-
Bore Size: 56.00mm
-
Actual Piston Size: 55.96mm
-
Display Displacement: 124 cm³
-
Stroke: 50.60mm
-
Piston Clearance: 0.05mm
-
Wossner Compression Ratio: 2-stroke
-
OEM Compression Ratio: 2-stroke
-
Dome Volume: Flat
-
Compression Height: 25.00mm
-
Lock Part Number: CW16
-
Pin Part Number: WP036
-
Ring Set Part Number: 2 x RSB5600
Cross-Reference OEM Part Numbers
-
Part No: 56-W940+00B.WO
Vehicle Fitments
-
Cagiva Mito 125 (1993–1998)
-
Cagiva Raptor 125 (2000–2012)
-
Cagiva Supercity 125 (2000–2012)
-
Cagiva Planet 125 (2000–2012)
-
Cagiva W8 125 (2000–2012)
-
Cagiva Head 200H,M (2000–2012)
