PISTON KIT 10-13 FE390 95.00 A, WOSSNER 8824DA

Wossner forged piston kit 8824DA is a standard-size piston with a 95mm bore (measured at 94.95mm), engineered for the Husaberg FE390 fuel-injected models from 2010 to 2012. Manufactured in Germany, this piston delivers superior strength, optimal thermal performance, and a precise fit for high-demand four-stroke engines.

Features

• Forged construction ensures exceptional strength and durability

• Elliptical design provides uniform bearing surface under heat expansion

• Optimised heat transfer from the combustion chamber to cylinder walls

• Minimises localised stress to reduce the risk of piston collapse

• Made in Germany

Specifications

• Bore: 95mm (Measured: 94.95mm)

• Display Volume: 398 cm³

• Stroke: 55.50mm

• Clearance: 0.05mm

• Compression Height: 23.20mm

• Wossner Compression Ratio: OEM

• OEM Compression Ratio: 11.10:1

• Dome Volume: -1.10 cm³

• Part No.: 56-W918.A.WO (Wossner 8824DA)

• Ring Set: 950ADS-2

• Lock P/N: CW19

• Pin P/N: WP071

Vehicle Fitments

• 2010 Husaberg FE390

• 2011 Husaberg FE390

• 2012 Husaberg FE390
