| Size | 73mm |
|---|---|
| Product Type | Pistons & Kits |
| Product Group | Engine |
| Catalogue | DIRT |
| Piston Diameter | 73.0 |
| Bore Diameter | |
| Piston Grade | |
| Compression Ratio |
PISTON KIT 002-09 DRZ250 73 HC, FORGED WOSSNER 8678D700
Wossner forged high-compression big bore piston kit with an 80mm bore (79.95mm) for Suzuki DR-Z250 (2001-2007). Designed for superior strength and heat transfer efficiency, this piston ensures optimal combustion performance. The elliptical design distributes thrust loads evenly, reducing localized pressure and preventing piston collapse. Manufactured in Germany.
Features
- High-compression forged piston for increased performance
- Big bore design for enhanced displacement
- Optimized heat transfer for improved efficiency
- Elliptical design ensures uniform bearing surface under heat expansion
- Even thrust load distribution to prevent piston collapse
- Manufactured in Germany
Specifications
- Bore Size: 80mm (79.95mm)
- Compression Ratio: 11.5:1
- Part Number: 8678D700
- Lock Part Number: CW19
- Pin Part Number: WP028
- Ring Set Part Number: 800XDS
- Stroke: 59.60mm
- Clearance: 0.05mm
- OEM Compression Ratio: 10.4:1
- Dome Volume: -1.40 cm³
- Compression Height: 24.00mm
Vehicle Fitments
- Suzuki DR-Z250 (2001-2007)
