PISTON KIT 00-03 RM125 55.00, WOSSNER 8061D100 SUZUKI MX

This Wossner piston kit features a 55.00mm bore, designed as a +1.00mm oversize replacement for high-performance 2-stroke engines. Built with forged construction, it offers exceptional strength and heat handling characteristics, ideal for demanding conditions in racing or heavy-duty off-road use. Compatible with Suzuki RM125 models from 2000 to 2003.

Features

• Forged piston for maximum strength and durability under stress

• Designed for efficient combustion heat transfer to the cylinder wall

• Elliptical shape enables uniform load distribution under thermal expansion

• Minimises the risk of piston collapse by preventing localised pressure build-up

• Precision-manufactured in Germany

Specifications

• Bore: 55.00 mm

• Actual piston size: 54.95 mm

• Stroke: 54.50 mm

• Display volume: 125 cm³

• Clearance: 0.05 mm

• Compression ratio: 2-stroke (Wossner and OEM)

• Compression height: 29.50 mm

Cross-Reference OEM Part Numbers

• Piston Kit: 8061D100

• Lock: CW15

• Pin: WP032

• Ring Set: RSB5500

• Rod: P2013

• Part No: 56-W754.100.WO

Vehicle Fitments

• Suzuki RM125 2000

• Suzuki RM125 2001

• Suzuki RM125 2002

• Suzuki RM125 2003
