OIL SEAL 28x42x7, ATHENA M730902060000 MGR-SD

ATHENA OIL SEALS – M730902060000

Description

Oil seal has generally the function of retaining a fluid, preventing its leaking. The outside has to ensure a fixed-fitting in the seat and its tightness. Thanks to its specific profile together with the radial force applied by the spring and the characteristics of the elastomer, the sealing lip flows on the shaft creating a barrier that prevents the leakage of the fluid both in static and dynamic condition. Every Athena oil seal is in accordance with the DIN 3760 requirements. Oil seals are available in different sizes, shapes and dimensions.

Technical features

• External Diameter (mm) 42.00
• Height 7.00
• Internal Diameter (mm) 28.00
• Net Weight (Kg) 0.01
• Number Of Components 20
• Type TC

Partner Cross Reference code

• 91257-230-003
• 28X42X7
• 92049-Y016
• 91257-230-000
• 91257-230-000
• 91257-230-005

Vehicle Compatibility

• 1976 CB125S A REAR WHEEL
• 1976 MT125 A REAR WHEEL
• 1976 TL125S A REAR WHEEL
• 1976 XL100 A REAR WHEEL
• 1976 XL125 A REAR WHEEL
• 1977 CT125 A REAR WHEEL
• 1977 XL100 A REAR WHEEL
• 1977 XL125 A REAR WHEEL
• 1978 CB125S A REAR WHEEL
• 1978 CM185T A REAR WHEEL
• 1977 CT125 A – REAR WHEEL
• 1977 XL100 A – REAR WHEEL
• 1977 XL125 A – REAR WHEEL
• 1978 CB125S A – REAR WHEEL
• 1978 CM185T A – REAR WHEEL
• 1978 CR250R A – REAR WHEEL
• 1978 XL100 A – REAR WHEEL
• 1978 XL125 A – REAR WHEEL
• 1979 CB125S A – REAR WHEEL
• 1979 CM185T A – REAR WHEEL
• 1979 CR250R A – REAR WHEEL
• 1979 XL100S A – REAR WHEEL
• 1979 XL125S A – REAR WHEEL
• 1979 XL185S A – REAR WHEEL
• 1979 XR185 A – REAR WHEEL
• 1980 CB125S A – REAR WHEEL
• 1980 CM200T A – REAR WHEEL
• 1980 CR250R A – REAR WHEEL
• 1980 XL100S A – REAR WHEEL
• 1980 XL125S A – REAR WHEEL
• 1980 XL185S A – REAR WHEEL
• 1980 XR200 A – REAR WHEEL
• 1981 CB125S A – REAR WHEEL
• 1981 CM200T A – REAR WHEEL
• 1981 CR250R A – REAR WHEEL
• 1981 CR450R A – REAR WHEEL
• 1981 XL125S A – REAR WHEEL
• 1981 XL185S A – REAR WHEEL
• 1981 XR200 A – REAR WHEEL
• 1982 CB125S A – REAR WHEEL
• 1982 CM200T A – REAR WHEEL
• 1982 CR125R A – REAR WHEEL
• 1982 CR250R A – REAR WHEEL
• 1982 CR480R A – REAR WHEEL
• 1982 CX500TC A – REAR WHEEL
• 1982 XL125S A – REAR WHEEL
• 1982 XL185S A – REAR WHEEL
• 1982 XR200 A – REAR WHEEL
• 1983 CX650T A – REAR WHEEL
• 1983 XL185S A – REAR WHEEL
• 1983 XL185S AC – REAR WHEEL
• 1983 XR200 A – REAR WHEEL
• 1984 CB125S A – REAR WHEEL
• 1984 CB125S AC – REAR WHEEL
• 1984 XL125S A – REAR WHEEL
• 1984 XL125S AC – REAR WHEEL
• 1984 XR200 A – REAR WHEEL
• 1985 CB125S A – REAR WHEEL
• 1985 CB125S AC – REAR WHEEL
• 1985 CMX250C A – REAR WHEEL
• 1985 CMX250C AC – REAR WHEEL
• 1985 XL125S A – REAR WHEEL
• 1985 XL125S AC – REAR WHEEL
• 1986 CMX250C A – REAR WHEEL
• 1986 CMX250C AC – REAR WHEEL
• 1986 CMX250CD A – REAR WHEEL
• 1986 CMX250CD AC – REAR WHEEL
• 1986 TR200 A – REAR WHEEL
• 1987 CMX250C A – REAR WHEEL
• 1987 CMX250C AC – REAR WHEEL
• 1987 TR200 A – REAR WHEEL
• 1990 CB125TT A – REAR WHEEL
• 1990 CB125TT AC – REAR WHEEL
• 1991 CB250 A – REAR WHEEL (1)
• 1991 CB250 AC – REAR WHEEL (1)
• 1992 CB250 A – REAR WHEEL (1)
• 1992 CB250 AC – REAR WHEEL (1)
• 1993 CB250 A – REAR WHEEL (2)
• 1993 CB250 AC – REAR WHEEL (2)
• 1994 CB250 A – REAR WHEEL (2)
• 1994 CB250 AC – REAR WHEEL (2)
• 1995 CB250 A – REAR WHEEL (2)
• 1995 CB250 AC – REAR WHEEL (2)
• 1996 CB250 A – REAR WHEEL (2)
• 1996 CB250 AC – REAR WHEEL (2)
• 1996 CMX250C A – REAR WHEEL
• 1997 CB250 A – REAR WHEEL (2)
• 1997 CB250 AC – REAR WHEEL (2)
• 1997 CMX250C A – REAR WHEEL
• 1997 CMX250C AC – REAR WHEEL
• 1999 CB250 A – REAR WHEEL (2)
• 1999 CB250 AC – REAR WHEEL (2)
• 1999 CMX250C A – REAR WHEEL
• 1999 CMX250C AC – REAR WHEEL
• 1999 CMX250C2 A – REAR WHEEL
• 1999 CMX250C2 AC – REAR WHEEL
• 2000 CB250 A – REAR WHEEL
• 2000 CB250 AC – REAR WHEEL
• 2000 CMX250C A – REAR WHEEL
• 2000 CMX250C AC – REAR WHEEL
• 2000 CMX250C2 A – REAR WHEEL
• 2000 CMX250C2 AC – REAR WHEEL
• 2000 XR650R A – REAR WHEEL
• 2000 XR650R AC – REAR WHEEL
• 2001 CB250 A – REAR WHEEL
• 2001 CB250 AC – REAR WHEEL
• 2001 CMX250C A – REAR WHEEL
• 2001 CMX250C AC – REAR WHEEL
• 2001 XR650R A – REAR WHEEL
• 2001 XR650R AC – REAR WHEEL
• 2002 CB250 A – REAR WHEEL
• 2002 CB250 AC – REAR WHEEL
• 2002 CMX250C A – REAR WHEEL
• 2002 CMX250C AC – REAR WHEEL
• 2002 XR650R A – REAR WHEEL
• 2002 XR650R AC – REAR WHEEL
• 2003 CB250 A – REAR WHEEL
• 2003 CB250 AC – REAR WHEEL
• 2003 CMX250C A – REAR WHEEL
• 2003 CMX250C AC – REAR WHEEL
• 2003 XR650R A – REAR WHEEL
• 2003 XR650R A/A – REAR WHEEL
• 2003 XR650R AC – REAR WHEEL
• 2003 XR650R AC/A – REAR WHEEL
• 2004 CB250 A – REAR WHEEL
• 2004 CB250 AC – REAR WHEEL
• 2004 CMX250C A – REAR WHEEL
• 2004 CMX250C AC – REAR WHEEL
• 2004 XR650R A – REAR WHEEL
• 2004 XR650R AC – REAR WHEEL
• 2005 CB250 A – REAR WHEEL
• 2005 CB250 AC – REAR WHEEL
• 2005 CMX250C A – REAR WHEEL
• 2005 CMX250C AC – REAR WHEEL
• 2005 XR650R A – REAR WHEEL
• 2005 XR650R A/A – REAR WHEEL
• 2005 XR650R A/B – REAR WHEEL
• 2005 XR650R AC – REAR WHEEL
• 2005 XR650R AC/A – REAR WHEEL
• 2005 XR650R AC/B – REAR WHEEL
• 2006 CB250 A – REAR WHEEL
• 2006 CB250 AC – REAR WHEEL
• 2006 CMX250C A – REAR WHEEL
• 2006 CMX250C AC – REAR WHEEL
• 2006 XR650R A – REAR WHEEL
• 2006 XR650R AC – REAR WHEEL
• 2007 CB250 A – REAR WHEEL
• 2007 CB250 AC – REAR WHEEL
• 2007 CBR600RR A – FRONT WHEEL
• 2007 CBR600RR AC – FRONT WHEEL
• 2007 CMX250C A – REAR WHEEL
• 2007 CMX250C AC – REAR WHEEL
• 2007 XR650R A – REAR WHEEL
• 2008 CB250 A – REAR WHEEL
• 2008 CB250 AC – REAR WHEEL
• 2008 CBR600RR 2A – FRONT WHEEL
• 2008 CBR600RR 2A/A – FRONT WHEEL
• 2008 CBR600RR 3AC – FRONT WHEEL
• 2008 CBR600RR 3AC/A – FRONT WHEEL
• 2008 CBR600RR A – FRONT WHEEL
• 2008 CBR600RR A/A – FRONT WHEEL
• 2008 CBR600RR AC – FRONT WHEEL
• 2008 CBR600RR AC/A – FRONT WHEEL
• 2008 CMX250C A – REAR WHEEL
• 2008 CMX250C AC – REAR WHEEL
• 2009 CBR600RA A – FRONT WHEEL
• 2009 CBR600RA AC – FRONT WHEEL
• 2009 CBR600RR 2A – FRONT WHEEL
• 2009 CBR600RR 3AC – FRONT WHEEL
• 2009 CBR600RR A – FRONT WHEEL
• 2009 CBR600RR AC – FRONT WHEEL
• 2009 CMX250C A – REAR WHEEL
• 2009 CMX250C AC – REAR WHEEL
• 2010 CBR600RA AC – FRONT WHEEL
• 2010 CBR600RR 2A – FRONT WHEEL
• 2010 CBR600RR 3AC – FRONT WHEEL
• 2010 CBR600RR A – FRONT WHEEL
• 2010 CBR600RR AC – FRONT WHEEL
• 2011 CBR600RA AC – FRONT WHEEL
• 2011 CBR600RR 3AC – FRONT WHEEL
• 2011 CBR600RR A – FRONT WHEEL
• 2011 CBR600RR AC – FRONT WHEEL
• 2012 CBR600RA AC – FRONT WHEEL
• 2012 CBR600RR 2A – FRONT WHEEL
• 2012 CBR600RR 3AC – FRONT WHEEL
• 2012 CBR600RR A – FRONT WHEEL
• 2012 CBR600RR AC – FRONT WHEEL
• 2012 CMX250C A – REAR WHEEL
• 2012 CMX250C AC – REAR WHEEL
• 2013 CBR600RA AC – FRONT WHEEL
• 2013 CBR600RR 2A – FRONT WHEEL
• 2013 CBR600RR 3AC – FRONT WHEEL
• 2013 CBR600RR 4A – FRONT WHEEL
• 2013 CBR600RR 5AC – FRONT WHEEL
• 2013 CBR600RR A – FRONT WHEEL
• 2013 CBR600RR AC – FRONT WHEEL
• 2013 CMX250C A – REAR WHEEL
• 2013 CMX250C AC – REAR WHEEL
• 2014 CBR600RA AC – FRONT WHEEL
• 2014 CBR600RR 2A – FRONT WHEEL
• 2014 CBR600RR 3AC – FRONT WHEEL
• 2014 CBR600RR A – FRONT WHEEL
• 2014 CBR600RR AC – FRONT WHEEL
• 2014 CMX250C A – REAR WHEEL
• 2014 CMX250C AC – REAR WHEEL
• 2015 CBR600RA AC – FRONT WHEEL
• 2015 CBR600RR A – FRONT WHEEL
• 2015 CBR600RR AC – FRONT WHEEL
• 2015 CMX250X 2A – REAR WHEEL
• 2015 CMX250X 3AC – REAR WHEEL
• 2016 CBR600RA 7AC – FRONT WHEEL
• 2016 CBR600RR 6A – FRONT WHEEL
• 2016 CBR600RR 7AC – FRONT WHEEL
• 2016 CMX250X 2A – REAR WHEEL
• 2016 CMX250X 3AC – REAR WHEEL
• 2017 CBR600RA 7AC – FRONT WHEEL
• 2017 CBR600RR 6A – FRONT WHEEL
• 2017 CBR600RR 7AC – FRONT WHEEL
• 2018 CBR600RA 7AC – FRONT WHEEL
• 2018 CBR600RR 6A – FRONT WHEEL
• 2018 CBR600RR 7AC – FRONT WHEEL
• 2019 CBR600RA 7AC – FRONT WHEEL
• 2019 CBR600RA AC – FRONT WHEEL
• 2019 CBR600RR 6A – FRONT WHEEL
• 2019 CBR600RR 7AC – FRONT WHEEL
• 2019 CBR600RR A – FRONT WHEEL
• 2019 CBR600RR AC – FRONT WHEEL
• 2020 CBR600RA 7AC – FRONT WHEEL
• 2020 CBR600RA AC – FRONT WHEEL
• 2020 CBR600RR 6A – FRONT WHEEL
• 2020 CBR600RR 7AC – FRONT WHEEL
• 2020 CBR600RR A – FRONT WHEEL
• 2020 CBR600RR AC – FRONT WHEEL
• 2020 CRF1100A 2AC – FRONT WHEEL (1)
• 2020 CRF1100A AC – FRONT WHEEL (1)
• 2020 CRF1100A4 2AC – FRONT WHEEL (2)
• 2020 CRF1100D 2AC – FRONT WHEEL (1)
• 2020 CRF1100D AC – FRONT WHEEL (1)
• 2020 CRF1100D4 2AC – FRONT WHEEL (2)
• 2021 CBR600RA 7AC – FRONT WHEEL
• 2021 CBR600RR 6A – FRONT WHEEL
• 2021 CBR600RR 7AC – FRONT WHEEL
• 2021 CRF1100A 3AC – FRONT WHEEL (1)
• 2021 CRF1100A4 AC – FRONT WHEEL (2)
• 2021 CRF1100D 3AC – FRONT WHEEL (1)
• 2021 CRF1100D4 AC – FRONT WHEEL (2)
• 2012 BRUTE FORCE 300 (KVF300CCF) – Front Hub
• 2013 BRUTE FORCE 300 (KVF300CDF) – Front Hub
• 2014 BRUTE FORCE 300 (KVF300CEF) – Front Hub
• 2015 BRUTE FORCE 300 (KVF300CFF) – Front Hub
• 2016 BRUTE FORCE 300 (KVF300CGF) – Front Hub
• 2017 BRUTE FORCE 300 (KVF300CHF) – Front Hub
• 2018 BRUTE FORCE 300 (KVF300CJF) – Front Hub
• 2020 BRUTE FORCE 300 (KVF300CLF) – Front Hub
• 2021 Brute Force 300 (KVF300CMFNN) – Front Hub



Part No. 58-8059.ATH (oro2u.com)
