LEFT RACK & PINION REBUILD KIT, ALLBALLS 51-1054-L, Can-Am

Kit Contents
Rack and Pinion End Kit – Left Hand Side – 0430-0747 ALLBALLS 51-1054-L

UTV steering rack rod ends save customers hundreds of dollars on the cost of a complete steering rack assembly. The inner rod assemblies have increased shaft diameters for improved strength. Each kit includes heavy-duty inner and outer rod ends with a replacement boot, clamps, and any required lock washers. Outer tie rod ends are also available individually.

Description & Quantity per Kit:

• Boot: 1
• Miscellaneous Part: 1
• Miscellaneous Part: 1
• Tie Rod: 2
• Tie Rod End: 1

Included Items:

• (1) 14mm-1.50 right-hand thread tie rod end
• (1) 14mm-1.50 hex nut
• (1) 12mm-1.75 x 90mm hex head bolt
• (1) 12mm-1.75 nyloc nut
• (2) 12mm ID x 25mm OD flat washers
• (1) 12mm ID x 32mm OD flat washer
• (1) 16mm-1.50/14mm-1.50 right-hand thread rack end
• (1) 14mm-1.50 x 310mm internal right-hand thread tie rod
• (1) Black rubber boot
• (2) 7 1/2 in. black plastic cable ties

Fitment List

Can-Am

• 2013-2018 Can-Am Maverick 1000 STD
• 2016-2017 Can-Am Maverick 1000 TURBO
• 2015-2016 Can-Am Maverick 1000 TURBO XDS
• 2016 Can-Am Maverick 1000 TURBO XRS
• 2016-2017 Can-Am Maverick 1000 XC
• 2015-2016 Can-Am Maverick 1000 XDS
• 2014-2018 Can-Am Maverick 1000 XMR
• 2013-2015 Can-Am Maverick 1000 XRS
• 2017 Can-Am Maverick 1000 XXC
• 2015-2018 Can-Am Maverick MAX 1000 STD
• 2016-2017 Can-Am Maverick MAX 1000 TURBO
• 2015-2017 Can-Am Maverick MAX 1000 TURBO XDS
• 2016-2017 Can-Am Maverick MAX 1000 TURBO XRS
• 2016 Can-Am Maverick MAX 1000 XC/XXC
• 2015-2016 Can-Am Maverick MAX 1000 XDS
• 2017-2018 Can-Am Maverick MAX 1000 XMR
• 2015 Can-Am Maverick MAX 1000 XRS

Left Rack & Pinion Rebuild Kit
ALLBALLS 51-1054-L
Includes heavy-duty tie rod outer end and boot.
