HEAVY DUTY STEEL BALL BEARING DRAWER RUNNERS SELF-LOCKING 350â690mm
Brand: Factory Image Racing
Stock: 5
HEAVY DUTY STEEL BALL BEARING DRAWER RUNNERS SELF-LOCKING 350â690mm
A heavy-duty steel ball bearing drawer runner designed for reliable, smooth operation. It features caged ball bearings, a hold-closed self-locking mechanism, and adjustable mounting to suit precise installations. Closed length is 350 mm, extending to 690 mm, with a 45 mm runner height and a 45 kg load rating per set of runners.
Features
- Heavy-duty steel construction
- Caged ball bearings for smooth sliding
- Self-locking mechanism to keep drawers closed
- Extends from 350 mm (closed) to 690 mm (open)
- 4 mm mounting holes with 6 mm of adjustment
- Runner height 45 mm
- Rated for 45 kg per set of runners
- Quick Release for easy drawer removal
Specifications
- Material: Steel
- Bearing type: Caged ball bearings
- Closed length: 350 mm
- Fully extended length: 690 mm
- Extension travel: 340 mm
- Runner height: 45 mm
- Mounting holes: 4 mm diameter with 6 mm adjustment
- Load rating: 45 kg per set of runners
- Mechanism: Self-locking (hold-closed)
