FUEL VALVE KIT YFM350 04-07, All Balls FS101-0049 YAMAHA ATV, TAPE / PETCOCK / CLIPS / PIPES / BOLTS

The All Balls FS101-0049 Fuel Valve Kit is a complete replacement petcock assembly designed for select Yamaha ATV models. Engineered to match OEM specifications, the kit includes all necessary components for a direct-fit installation on 2004–2006 Yamaha Bruin 350 and 2007 Yamaha Grizzly 350 models.

Features

• Complete replacement fuel petcock assembly

• Includes fuel line, clamps, mounting hardware, and knob

• Direct-fit design for specified Yamaha ATV models

• Sold individually

Specifications

• (1) Fuel valve assembly

• (1) Rubber fuel line

• (2) Fuel line clamps

• (1) Plastic on/off fuel knob

• (1) 4mm-.70 x 15mm tapered Phillips head screw

• (2) 6mm-1.00 x 15mm Phillips washer head bolts

• (2) Mounting spacers

Cross-Reference OEM Part Numbers

• 5KM-24500-00-00 (Fuel Cock Assy)

• 5KM-24500-10-00 (Fuel Cock Assy)

• 3AJ-24523-00-00 (Valve Packing)

• 3AC-24523-00-00 (Valve Packing)

• 3AJ-24534-00-00 (Seal, Cock)

• 3AJ-24534-01-00 (Seal, Cock)

• 98507-03014-00 (Screw, Pan Head)

• 4X8-24512-00-00 (O-Ring)

• 5GH-24524-00-00 (Lever, Cock)

• 1NS-F4524-00-00 (Lever, Cock)

• 98707-04018-00 (Screw, Flat Head)

• 90202-05193-00 (Washer, Plate)

• 90202-05187-00 (Washer, Plate)

• 90149-06011-00 (Screw)

• 5UH-F4311-00-00 (Pipe, Fuel 1)

• 90467-10008-00 (Clip)

• 90467-100A1-00 (Clip)

Vehicle Fitments

• 2004 Yamaha YFM350FA Bruin 4×4

• 2005 Yamaha YFM350FA Bruin 4×4

• 2006 Yamaha YFM350FA Bruin 4×4

• 2004 Yamaha YFM350FAH Bruin 4×4 Hunter Edition

• 2005 Yamaha YFM350FAH Bruin 4×4 Hunter Edition

• 2006 Yamaha YFM350FAH Bruin 4×4 Hunter Edition

• 2007 Yamaha YFM350FG Grizzly 4×4

• 2007 Yamaha YFM350FGI Grizzly 4×4 IRS

• 2007 Yamaha YFM350FGIH Grizzly 4×4 IRS Hunter Edition

• 2007 Yamaha YFM350G Grizzly
