CONNECTING ROD KIT MAICO 250, RO-8208 125-18-22-16-16-58.5mm, NAMURA RX-12001, MX-09066
£129.16
Brand: Namura Technologies
Stock: 18
| Product Type | Connecting Rod |
|---|---|
| Product Group | Crankshafts & Parts |
| Catalogue | DIRT |
CONNECTING ROD KIT MAICO 250, RO-8208 125-18-22-16-16-58.5mm, NAMURA RX-12001, MX-09066
MAICO
- MAICO 250/320 ENGINES 1983-ON
CONNECTING CONROD ROD REBUILD KIT.
– Heavy-duty OE replacement connecting rods.
– Certified Chorme alloy steel provides superior strength.
– Crankpins are manufactured from hot-rolled ASTM steel and case hardened.
– Thrust washers are manufactured from bronze phosphor and are silver coated.
– Rod assembly sold complete with rod, crankpin, crankpin bearing, top end bearing and thrust washers if need.
– Fully Compatible with after market and OE crankshafts.
– Material SNCM220,
|
SIZE |
MM |
|
Centre 2 Centre |
125 |
|
Small End Bearing |
18x22x23.5 |
|
Small End Bore Ø |
22 |
|
Small End Width |
16 |
|
Big End Bearing |
22x28x15.8 |
|
Big End Bore Ø |
28 |
|
Big End Width |
16 |
|
Big End Pin Ø |
22 |
|
Big End Pin Length |
58.50 |
|
Washer Thickness |
22x39x1.3 |
CONNECTING ROD SIZE PLEASE SEE DRAWING SIZE mm. A = 125, B = 18, C = 22, D = 16, E = 16, F = 58.5
Cross reference numbers ONLY.
RO-8208, MX-09066
