| Product Type | Connecting Rod |
|---|---|
| Product Group | Crankshafts & Parts |
| Catalogue | DIRT |
CONNECTING ROD 97-02 KTM60/65, PSYCHIC MX-09041 46030015000
KTM
SX60 / SX65 1998-2002,
CONNECTING CONROD ROD REBUILD KIT. PSYCHIC MX-09041
– Heavy-duty OE replacement connecting rods.
– Certified Chorme alloy steel provides superior strength.
– Crankpins are manufactured from hot-rolled ASTM steel and case hardened.
– Psychic Rods uses the latest in caged needle roller bearing designs for high rpm longevity.
– Thrust washers are manufactured from bronze phosphor and are silver coated.
– Rod assembly sold complete with rod, crankpin, crankpin bearing, top end bearing and thrust washers if need.
– Fully Compatible with after market and OE crankshafts.
– Material SNCM220,
|
SIZE |
MM |
|
Centre 2 Centre |
88 |
|
Small End Bearing |
12x15x16.3 |
|
Small End Bore Ø |
15 |
|
Small End Width |
13 |
|
Big End Bearing |
18x24x14.8 |
|
Big End Bore Ø |
24 |
|
Big End Width |
14.90 |
|
Big End Pin Ø |
18 |
|
Big End Pin Length |
56 |
|
Washer Thickness |
1.00 |
Part No. 56-958.DR (oro2u.com)
Cross reference numbers ONLY.
MX-09041, HOTRODS 8625, 46030015000 ,
