CDI BOX HON ROAD CB XL CH, 30410-KB1-930, 30410-KN7-670 30410-KN7-670 / 30410-KB7-671 / 30410-KB7-940 / 30410-MC4-003, IHA6005 SCOOTER
£64.13
Brand: Arrowhead Electrical
Out of Stock
| Product Type | CDI Box |
|---|---|
| Product Group | Ignition & Electrical Parts |
| Catalogue | ROAD |
CDI BOX HON ROAD CB XL CH, 30410-KB1-930, 30410-KN7-670 30410-KN7-670 / 30410-KB7-671 / 30410-KB7-940 / 30410-MC4-003, IHA6005 SCOOTER
Honda
CB125S 1985,
XL125 1985-86,
CH150 Elite (Scooter),
CH150D Elite (Scooter) 1985-86,
CBX Aero 15cc (1990 a 1997)
CGL 125cc Elite CH150 150cc (1985 a 1987)
Elite CH150D 150cc (1985 a 1987)
SDH Storm 4G 125cc ( 2003 a 2006)
Wave 100cc
XL R 250cc (1982 a 1983)
XL Duty 125cc
XL S 125cc
XL R 500cc (1982)
Scout D 250cc
| Información técnica | |
| Punto de encendido (ignition timing) | AVANCE |
| Sistema electronico (type) | ANALOGICO |
| Alimentacion del encendido (input) | BOBINA (AC) |
| # salidas (# output) | 1 |
| Alto (height) | 23 [mm] |
| Ancho (width) | 38 [mm] |
| Largo (length) | 68 [mm] |
| # terminales (# terminals) | 6 |
| Potenciado (enhaced) | NO |
| dze que aplican a | |||||
| Marca | Modelo | Versión | Cilindrada | Año | Cod. OEM |
| Honda | CBX | Aero | 150 | de 1990 a 1997 | |
| Honda | CGL | 125 | |||
| Honda | Elite | CH150D | 150 | de 1985 a 1987 | 30410-KN7-670 |
| Honda | Elite | CH150 | 150 | de 1985 a 1987 | 30410-KN7-670 |
| Honda | SDH | Storm 4G | 125 | de 2003 a 2006 | |
| Honda | Wave | 100 | |||
| Honda | XL | Duty | 125 | ||
| Honda | XL | R | 500 | 1982 | 30410-MC4-003 |
| Honda | XL | S | 125 | ||
| Honda | XL | R | 250 | de 1982 a 1983 | 30410-KB7-940 |
| Honda | XL | R | 250 | de 1982 a 1983 | 30410-KB7-671 |
| Reemplazo | Pietcard | 2063 | |||
| Scout | D | 250 | |||
– Meets or exceeds OEM quality.
– Direct oem replacement.
– All products are factory tested for 100% reliability at point of sale.
– Designed to handle increased power loads.
– DZE Racing products are a high quality replacement part and carries our guarantee of your satisfaction.
– Please check the image and connection plugs before ordering to avoid mistakes.
– Note. No Returns on Electrical Parts.
Part No. 44-5972 (oro2u.com)
CDI Module For Honda Capacitive Discharge Ignition. With Electronic Advance.
SIZE 68mm L x 38mm W x 23mm H
Cross reference numbers.
30410-KB1-930, 30410-KN7-670, IHA6005 30410-KN7-670 / 30410-KB7-671 / 30410-KB7-940 / 30410-MC4-003
